Agilent 1200 Series HPLC System With G1311 Quat Pump, G1329 ALS, G1365 MWD

The Agilent 1200 Series HPLC system provides dependable gradient formation, precise injection control, and advanced UV-Vis detection in a compact, modular platform. This configuration features the G1311A quaternary pump for four-solvent low-pressure mixing, the G1329A autosampler for reliable and repeatable sample delivery, and the G1365 multi-wavelength detector for high-resolution spectral analysis across multiple wavelengths.

• Quaternary pump supports programmable low-pressure gradients with up to four solvents
• Autosampler ensures consistent injection precision and broad sample compatibility
• MWD captures UV-Vis absorbance at up to 8 wavelengths from 190 to 950 nm
• Well-suited for method development, QA/QC, and complex analytical workflows

Specifications:

• G1311A Quaternary Pump:
  • Flow rate: 0.2 – 10.0 mL/min; settable from 0.001 mL/min
  • Pressure range: up to 400 bar (5880 psi) at ≤5 mL/min
  • Flow accuracy: ±1% or 10 µL/min
  • Flow precision: ≤0.07% RSD or ≤0.02 min SD
  • Gradient formation: Low-pressure quaternary mixing; delay volume 800–1100 µL
  • Power: 220 VA; Voltage: 100–240 VAC, 50/60 Hz
  • Dimensions: 5.5 x 13.5 x 17 in (140 x 345 x 435 mm); Weight: 25 lbs (11 kg)
• G1329A Autosampler:
  • Injection range: 0.1–100 µL; up to 1500 µL with hardware modification
  • Precision: <0.25% RSD (5–100 µL); <1% RSD (1–5 µL)
  • Carryover: <0.1% standard; <0.05% with external needle cleaning
  • Sample capacity: 100 × 2 mL vials
  • Power: 300 VA max
  • Dimensions: 8 x 13.5 x 17 in (200 x 345 x 435 mm); Weight: 31.3 lbs (14.2 kg)
• G1365 Multiple Wavelength Detector:
  • Wavelength range: 190–950 nm
  • Simultaneous detection: Up to 8 wavelengths
  • Slit width: Programmable (1, 2, 4, 8, 16 nm)
  • Flow cells: Standard 13 µL, 10 mm path length, up to 120 bar
  • Noise: ±1 × 10⁻⁵ AU at 254/750 nm
  • Wavelength accuracy: ±1 nm; self-calibrating
  • Power: 300 VA / 125 W
  • Dimensions: 5.5 x 13.5 x 17 in (140 x 345 x 435 mm); Weight: 26 lbs (11.5 kg)

This system delivers precise gradient performance, repeatable injections, and comprehensive multi-wavelength UV-Vis detection—making it an excellent choice for diverse analytical applications.
