Agilent 1260 Series G1315D DAD VL

The Agilent 1260 Series G1315D DAD VL is a high-performance diode array detector designed for precise UV-Vis detection in liquid chromatography applications. With a broad wavelength range of 190–950 nm and a 1024-element photodiode array, it delivers exceptional spectral resolution and sensitivity. Its deuterium and tungsten lamps ensure reliable performance across the full spectrum, while multiple flow cell options accommodate diverse analytical needs.

Key Features & Benefits:

• Broad Wavelength Range: Covers 190–950 nm for versatile UV-Vis detection.
• High Sensitivity: Short-term noise as low as ± 0.7 x 10^-5 AU at 254 and 750 nm.
• Flexible Flow Cell Options: Standard, bio-inert, semi-micro, micro, semi-nano, nano, high-pressure, and preparative cells for various applications.
• Accurate & Stable Detection: Wavelength accuracy of ± 1 nm with low drift (<0.9 x 10^-3 AU/hr at 254 nm).
• Fast Data Acquisition: Supports up to 20 Hz data rate for high-speed analysis.
• User-Controlled Slit Width: Adjustable from 1 to 16 nm for optimized resolution.
• Seamless Integration: Compatible with Agilent ChemStation software for efficient control and data evaluation.

Specifications:

• Wavelength Range: 190–950 nm
• Light Source: Deuterium and tungsten lamps
• Detection Type: 1024-element photodiode array
• Linear Absorbance Range: > 2 AU (upper limit)
• Flow Cell Options: Volumes from 80 nL to 13 μL, with path lengths from 0.06 mm to 10 mm
• Pressure Range: Up to 400 bar (5800 psi) depending on flow cell type
• Dimensions: 7.1 x 13.5 x 17.2 inches (180 x 345 x 436 mm)
• Weight: 26.5 lbs (12 kg)
• Power Requirements: 100–240V, 50/60 Hz

The Agilent 1260 Series G1315D DAD VL offers high-resolution spectral detection with excellent sensitivity and stability. Its wide range of flow cell options, fast data acquisition, and seamless software integration make it a powerful choice for labs requiring precise and reproducible chromatography results.

Installation service & installation kits available.
