Eppendorf 5804R Refrigerated Centrifuge

The Eppendorf 5804R is a medium capacity refrigerated centrifuge capable of speeds up to 14,000 RPM. This high speed centrifuge features a temperature range from -9°  to 40° C, FastTemp function for pre-cooling prior to temperature control runs, continuous cooling when not in use and ECO shutoff after eight hours of non-use.

The 5804R also boasts a soft touch lid closure and a low access height for easy loading and unloading of samples, 10 different acceleration speeds with 10 braking ramps, a built-in condensation drain to help prevent corrosion and eliminate water accumulation, and internal memory sufficient to store up to 35 user-defined programs.

With a noise level of under 58 dB(A) this quiet centrifuge also boasts automatic rotor recognition and imbalance detection to maintain operational safety.

A dozen different rotors are available, including swing bucket rotors and adapters with an accommodation range from 0.2 mL to 250 mL; plate rotors for centrifugation of all types of MTP, PCR and cell cultures or fitting deep well plates; and fixed-angle rotors for tubes ranging from 0.2 mL to 85 mL. Ask your sales rep about rotor availability for this model.

Specifications:

• Max. RCF: 20,913 x gMax
• RCF with fixed-angle rotor: 20,913 x gMax
• RCF with swing bucket rotor: 4500 x gMax
• RCF with plate rotor: 2250 x gMax
• Speed: 200 – 14,000 RPM
• Max. capacity: 4 x 250 mL/2 x 5 MTP
• Rotors available: 12
• Display: large bright LCD
• Timer: 1-99 min
• Noise level: < 58 dB(A)
• Volume range: 1000 mL
• Power Supply: 120V, 50-60 Hz, 12 amp
• Max. power consumption: 1650 W
• Dimensions: 25.20 x 61.65 x 13.39 in. (64 x 55 x 34 cm)
• Height with lid open: 29.13 in. (74 cm)
• Weight without accessories: 176 lbs (80 kg)
• Temperature control range: -9° to 40° C (15.9° to 104° F)
