Hewlett Packard 3465A Digital Multimeter

Hewlett Packard 3465A Digital Multimeter Image

ITEM: 29188

This product is currently out of stock, please check our complete line of in-stock Conductivity by clicking the green link below or give one of the members of our sales team a call today at (860) 691-2213 so we can help you find a suitable replacement.



Hewlett Packard 3465A Digital Multimeter ImageHewlett Packard 3465A Digital Multimeter Image

The Hewlett Packard 3465A Digital Multimeter provides measurement for DC volts, AC volts, DC current, AC current and Ohms. Measurement can be made to four significant digits with a sample rate of 2.5 readings per second.

The Hewlett Packard 3465A Digital Multimeter is designed to deliver exceptional measurement capabilities, ensuring reliable and precise readings every time. The unit features rugged construction for durability and longevity. The sturdy casing of the Hewlett Packard 3465A Digital Multimeter provides protection against accidental drops and impacts, making it a reliable tool for laboratory use.
Features:

  • Maximum DC Volts: 1000 V
  • Maximun AC Volts: 600 V DC; 500 V AC rms, 800 V peak AC
  • Maximum Volts, Ohms: 350 V

Specifications:

DC Voltmeter
Ranges: 20 mV, 200 mV, 2 V, 20 V, 200 V, 1000 V
Temperature Coefficient: 0 to 50°C; +/- 0.003% of reading /°C

DC Ammeter
Ranges: 200 µA, 2 mA, 20 mA, 200mA, 2,000 mA
Max. Input: 2 A from < 250 V source
Protection: 2 A/250 V fuse

AC Voltmeter
Ranges: 200 mV, 2 V, 20 V, 200 V, 500 V
Temperature Coefficient: 0 to 50°C; +/- 0.05% of reading + .2 counts /°C

AC Ammeter
Ranges: 200 µA, 2 mA, 20 mA, 200mA, 2,000 mA
Temperature Coefficient: 0 to 50°C; +/- 0.01% of reading /°C

Ohmmeter
Ranges: 200 Ω, 2 kΩ, 200 kΩ, 2,000 kΩ, 20 MΩ
Temperature Coefficient: 200 Ω through 2 MΩ; 0 to 50°C; +/- 0.0015% of reading /°C; 20 MΩ; +/- 0.004%
