PerkinElmer Series 200 Flourescence Detector

The Perkin Elmer Series 200 Flourescence Detector optimizes your analyses no matter the application. Features include: programmable time, spectrum memory, background subtraction, totally inert flow cells, and stackable with the 200 Series family.

Specifications:
– Measurement Methods: Ratio photometry using transmitted light monitor
– Light Source: Xenon lamp
– Excitation Wavelength Range: 200 to 850 nm and Zero Order
– Emission Wavelength Range: 250 to 900 nm and Zero Order
– Bandwidth: 15 nm
– Wavelength Accuracy: +/- 4 nm
– Wavelength Reproducibility: +/- 0.5 nm
– Response: 5 settings (0.1, 0.5, 2.0, 4.0, 8.0 sec)
– Sensitivity: S/N ratio of > 300:1 for Raman spectrum of water
(PM set to high)
– Time Programmable: Up to 100 steps total for 9 programs. All time programs are battery backed up even with power off.
– Spectrum Memory: Up to 8 spectra may be stored, Excitation or
Emission. Background spectra can also be subtracted.
– Integrator Output: 1 V
– Recorder Output: 10 mV
– Autozero Range: 0 to 1000
– Offset Range: 0 to 1000
– Flow Cell Volume: 12 μL (with standard cell)
– Flow Cell Materials: Quartz, Fluoro resin
– Display: 2 lines by 40 characters backlit with LCD
– Operating Temperature Range: 4 ÌŠC to 35 ÌŠC
– Dimensions (H x W x D): 340mm wide x 230mm x 495mm deep
(13.4” W x 9.1” H x 19.5” D)
– Weight: Approx. 19 kg (41.9 lb)
