Coy Laboratory Products Anaerobic Monitor (CAM-12)

The Coy Laboratory Products CAM-12 Anaerobic Monitor detects O2 and H2 in an anaerobic chamber.

Features:

– Detects real-time transient level changes
– Adjustable alarm levels
– User replaceable sensors
– Each analyzer is especially calibrated to your specific background gas mix

Specifications:

– Size of Footprint: 6.25” Wide x 6.25” Deep, 39.0 sq in. (15.9 cm x 15.9 cm, 252.0 sq cm)
– Overall Dimensions: 6.25” Wide x 6.31” Deep x 3.35” High (15.9 cm x 16.03 cm x 8.52 cm)
– Weight: ~1.7 lbs (0.77 kg) (~3.0 lbs shipping weight)
– Power Requirements: ~18 watts 90 ~ 260VAC, 50 – 60 Hz
– Operating Environment: 15 to 42C Up to 90% Relative Humidity, Non-Condensing
– Resolution: O2: 1ppm from 0 -1500 ppm, and 5ppm from 1500 – 2000 ppm
          H2: 0.1% from 0 – 4.0%
– Accuracy: O2: 20ppm up to 700ppm
          H2: 1.0% up to 10.0% H2
– Operating Temperature & Humidity Range: Ambient to 42C and Non-Condensing
– Alarms – Oxygen: User-settable high alarm from 0 to 10,000ppm, in 5 ppm increments
           Flashing LED and message
           Audible tone can be silenced by the operator
– Alarms – Hydrogen: User-settable between 1.5 and 4% in 0.1% increments
           Flashing LED and message
           Audible tone can be silenced by the operator (unless the Hydrogen is above 5%)
– CO2 Compensation: User-settable from 1-20%
