Lindberg/Blue M 55035 Tube Furnace

Features of the Lindberg/Blue M 55035 Tube Furnace include:

• Compact, portable and lightweight design
• Split-hinge design simplifies loading and unloading
• Main power on/off switch on control panel
• Safety switch disconnects power to heating element when furnace is opened
• Long life type “K” thermocouple
• Optional RS485 Digital Communications Port
• Power: 120V / 7A / 800W
• Temperature Control: Digital Single Program, Multiple Segment Programmable Controller
• Process Tube Diameter: 1 in.  (2.54 cm)
• Heated Length: 12 in. (30.5 cm)
• Temperature Range: 100°C to 1100°C (212° to 2012°F)
• Display: LED
• Hertz: 50/60
• Outside Dimensions: 15 x 11 x 16 in. (38.1 x 28.0 x 40.6 cm)
• Chamber Dimensions (Dia x Tube): 1  x 12 in.  (2.5  x 61 cm )
