Sartorius Incucyte S3 Live-Cell Analysis Instrument With PHCBI Dual Stack CO2 Incubator, Model MCO-230AICUVLG-PA

The Sartorius Incucyte S3 Live-Cell Analysis Instrument paired with the PHCBI Dual Stack CO2 Incubator offers a powerful solution for real-time, label-free live-cell imaging and analysis. The Incucyte S3 features multiple fluorescence channels, high-definition phase imaging, and extensive software compatibility, making it ideal for monitoring a wide range of cellular processes. The PHCBI incubator ensures optimal cell culture conditions with precise temperature and CO2 control.

Key Features & Benefits

• Real-time live-cell imaging: Monitor cellular processes in real-time with the Incucyte S3’s fluorescence and phase imaging.
• Label-free HD phase imaging: Perform high-resolution, label-free imaging for accurate cell tracking and analysis.
• Temperature & CO2 control: The PHCBI Dual Stack CO2 incubator ensures precise environmental control with a temperature range from ambient +5ºC to 50ºC and CO2 control from 0% to 20%.
• UV decontamination: Standard 24-hour full chamber UV decontamination cycle for ensuring contamination-free conditions.
• Large storage capacity: The Incucyte S3 controller offers 27.3 TB of data storage, expandable to 60 TB with Incustore, making it suitable for long-term experiments and large datasets.
• Advanced imaging objectives: Includes 4X, 10X, and 20X objectives for versatile imaging and analysis of various sample types.

Specifications for Sartorius Incucyte S3

• Optical System: Green/Red fluorescence (Standard)
• Fluorescence Channels: 2
• Objectives: 4X, 10X, 20X (all included)
• Objective Automation: Automated turret
• Incubation Size Required: >200 L
• Incubation Temperature: Up to 42°C
• Microplate Compatibility: 6, 12, 24, 48, 96, 384-well
• Flask Compatibility: T-25, T-50, T-75, T-100, T-175, T-225
• Vesselware Compatibility: 35mm, 60mm, 100mm, 150mm dishes and chamber slides
• Operating System: 64-bit Windows 10
• Storage: 27.3 TB, Expandable RAID up to 32.7 TB
• Controller Memory: 64 GB

Specifications for PHCBI Dual Stack CO2 Incubator

• Exterior Dimensions: 30.3″ W x 28.7″ D x 35.6″ H (770 x 730 x 905 mm)
• Interior Dimensions: 25.3″ W x 20.6″ D x 27.6″ H (643 x 523 x 700 mm)
• Interior Volume: 8.1 cu. ft. (230 L)
• Temperature Control Range: Ambient +5ºC to 50ºC
• Temperature Uniformity: ±0.25ºC (at 37ºC, CO2: 5%, no load)
• CO2 Control Range: 0% to 20%
• CO2 Variation: ±0.15% (at 37ºC, CO2: 5%, no load)
• CO2 Sensor: Dual Infrared Sensor
• Decontamination: 24-hour full chamber UV decontamination
• Humidity Control: Natural evaporation, 95% R.H. ±5%
• Display: Color LCD touchscreen
• Outer Door: Painted steel
• Net Weight: 198 lbs (90 kg)

This combination of the Incucyte S3 and PHCBI Dual Stack CO2 Incubator offers a comprehensive solution for real-time cell analysis under optimal environmental conditions, making it ideal for cell biology, drug discovery, and tissue engineering applications.
